订单类 快递电子面单接口使用开发（京东快递电子面单 ）
一、 订单类
1、电子面单
电子面单接口支持多家快递物流公司单号获取、分拣码返回、面单打印、在线下单发货、通知快递员上门取件等功能，可用于电商平台、自营商城、打单工具、WMS仓储系统、APP等需要发货的场景，可有效提高商家的打印效率，帮助其降低运营成本。
产品优势
1.1打单效率提升4-6倍极速获取快递单号，打单效率提升4-6倍，每天节约2-3小时。
1.2对接方便，无需调试打印机专业的打印控件，90%以上打印机无需调试，直接打印极速发货。
1.3支持多家快递公司电子面单支持各家电子面单，60+官方标准模板，统一模板尺寸，打印过程无需换纸。
1.4单号自动绑定，省去人工成本订单&运单号自动绑定，方便追踪物流及后续收货管理等售后流程，单号随取随用，部分直营直接打印。
1.5隐私面单，保护用户隐私收件人、发件人真实手机号中间四位数加*，确保用户隐私不泄露并可正常收件。
2、预约取件
预约取件为用户解决在线发货需求，在线通知快递员上门取件，适用于在线下单、APP端下单、售后退货等。
产品优势
2.1预约实时反馈
订单实时预约，实时返回预约成功或失败标识。
2.2上门取件
快递公司会及时联系发件人并上门揽件。免费试用 >http://www.kdniao.com/reg
3、快递员上门取件
快递鸟上门取件，是电商平台为寄件用户提供一键下单到快递员，并在2小时上门取件的寄件服务。适用于在线寄件、退换货等业务。
3.1一键退货在app或后台一键退货，不用线下找快递员，不用苦苦等待即可完成发货。
3.2在线支付运费快递员上门取件与在线收款，通过APP在线支付运费，告别线下或私下转款等传统支付方式。
二、API技术文档
京东快递电子面单接口，
支持的消息接收方式：HTTP POST
请求方法的编码格式(utf-8)：”application/x-www-form-urlencoded;charset=utf-8″
接口提供：快递鸟
快递编码：JD
注册账号http://www.kdniao.com/reg→在官网登录进入用户管理后台，进行实名认证，开通接口→技术对接及联调（登陆官网使用调试平台进行测试）→上线
技术对接文档：http://www.kdniao.com/api-eorder
JSON请求
{
“OrderCode”: “012657700387”,
“ShipperCode”: “HTKY”,
“PayType”: 1,
“ExpType”: 1,
“Cost”: 1.0,
“OtherCost”: 1.0,
“Sender”: {
“Company”: “LV”,
“Name”: “Taylor”,
“Mobile”: “15018442396”,
“ProvinceName”: “上海”,
“CityName”: “上海”,
“ExpAreaName”: “青浦区”,
“Address”: “明珠路73号”
},
“Receiver”: {
“Company”: “GCCUI”,
“Name”: “Yann”,
“Mobile”: “15018442396”,
“ProvinceName”: “北京”,
“CityName”: “北京”,
“ExpAreaName”: “朝阳区”,
“Address”: “三里屯街道雅秀大厦”
},
“Commodity”: [
{
“GoodsName”: “鞋子”,
“Goodsquantity”: 1,
“GoodsWeight”: 1.0
}
],
“AddService”: [
{
“Name”: “COD”,
“Value”: “1020”
}
],
“Weight”: 1.0,
“Quantity”: 1,
“Volume”: 0.0,
“Remark”: “小心轻放”,
“IsReturnPrintTemplate”:1
}
C# demo
using System;
using System.Collections.Generic;
using System.IO;
using System.Linq;
using System.Net;
using System.Text;
using System.Web;
namespace KdGoldAPI
{
public class KdApiEOrderDemo
{
//电商ID
private string EBusinessID = “请申请http://www.kdniao.com/ServiceApply.aspx”;
//电商加密私钥，注意保管，不要泄漏
private string AppKey = “请申请http://www.kdniao.com/ServiceApply.aspx”;
//请求url, 正式环境地址：http://api.kdniao.cc/api/Eorderservice
private string ReqURL = “http://testapi.kdniao.cc:8081/api/EOrderService”;
/// <summary>
/// Json方式 电子面单
/// </summary>
/// <returns></returns>
public string orderTracesSubByJson()
{
string requestData = “{‘OrderCode’: ‘012657700312’,” +
“‘ShipperCode’:’YTO’,” +
“‘PayType’:1,” +
“‘ExpType’:1,” +
“‘Cost’:1.0,” +
“‘OtherCost’:1.0,” +
“‘Sender’:” +
“{” +
“‘Company’:’LV’,’Name’:’Taylor’,’Mobile’:’15018442396′,’ProvinceName’:’上海’,’CityName’:’上海’,’ExpAreaName’:’青浦区’,’Address’:’明珠路73号’},” +
“‘Receiver’:” +
“{” +
“‘Company’:’GCCUI’,’Name’:’Yann’,’Mobile’:’15018442396′,’ProvinceName’:’北京’,’CityName’:’北京’,’ExpAreaName’:’朝阳区’,’Address’:’三里屯街道雅秀大厦’},” +
“‘Commodity’:” +
“[{” +
“‘GoodsName’:’鞋子’,’Goodsquantity’:1,’GoodsWeight’:1.0}],” +
“‘AddService’:” +
“[{” +
“‘Name’:’COD’,’Value’:’1020′}],” +
“‘Weight’:1.0,” +
“‘Quantity’:1,” +
“‘Volume’:0.0,” +
“‘Remark’:’小心轻放’,” +
“‘IsReturnPrintTemplate’:1}”;
Dictionary<string, string> param = new Dictionary<string, string>();
param.Add(“RequestData”, HttpUtility.UrlEncode(requestData, Encoding.UTF8));
param.Add(“EBusinessID”, EBusinessID);
param.Add(“RequestType”, “1007”);
string dataSign = encrypt(requestData, AppKey, “UTF-8”);
param.Add(“DataSign”, HttpUtility.UrlEncode(dataSign, Encoding.UTF8));
param.Add(“DataType”, “2”);
string result = sendPost(ReqURL, param);
//根据公司业务处理返回的信息……
return result;
}
/// <summary>
/// Post方式提交数据，返回网页的源代码
/// </summary>
/// <param name=”url”>发送请求的 URL</param>
/// <param name=”param”>请求的参数集合</param>
/// <returns>远程资源的响应结果</returns>
private string sendPost(string url, Dictionary<string, string> param)
{
string result = “”;
StringBuilder postData = new StringBuilder();
if (param != null && param.Count > 0)
{
foreach (var p in param)
{
if (postData.Length > 0)
{
postData.Append(“&”);
}
postData.Append(p.Key);
postData.Append(“=”);
postData.Append(p.Value);
}
}
byte[] byteData = Encoding.GetEncoding(“UTF-8”).GetBytes(postData.ToString());
try
{
HttpWebRequest request = (HttpWebRequest)WebRequest.Create(url);
request.ContentType = “application/x-www-form-urlencoded”;
request.Referer = url;
request.Accept = “*/*”;
request.Timeout = 30 * 1000;
request.UserAgent = “Mozilla/4.0 (compatible; MSIE 6.0; Windows NT 5.1; SV1; .NET CLR 2.0.50727; .NET CLR 3.0.04506.648; .NET CLR 3.0.4506.2152; .NET CLR 3.5.30729)”;
request.Method = “POST”;
request.ContentLength = byteData.Length;
Stream stream = request.GetRequestStream();
stream.Write(byteData, 0, byteData.Length);
stream.Flush();
stream.Close();
HttpWebResponse response = (HttpWebResponse)request.GetResponse();
Stream backStream = response.GetResponseStream();
StreamReader sr = new StreamReader(backStream, Encoding.GetEncoding(“UTF-8”));
result = sr.ReadToEnd();
sr.Close();
backStream.Close();
response.Close();
request.Abort();
}
catch (Exception ex)
{
result = ex.Message;
}
return result;
}
///<summary>
///电商Sign签名
///</summary>
///<param name=”content”>内容</param>
///<param name=”keyValue”>Appkey</param>
///<param name=”charset”>URL编码 </param>
///<returns>DataSign签名</returns>
private string encrypt(String content, String keyValue, String charset)
{
if (keyValue != null)
{
return base64(MD5(content + keyValue, charset), charset);
}
return base64(MD5(content, charset), charset);
}
///<summary>
/// 字符串MD5加密
///</summary>
///<param name=”str”>要加密的字符串</param>
///<param name=”charset”>编码方式</param>
///<returns>密文</returns>
private string MD5(string str, string charset)
{
byte[] buffer = System.Text.Encoding.GetEncoding(charset).GetBytes(str);
try
{
System.Security.Cryptography.MD5CryptoServiceProvider check;
check = new System.Security.Cryptography.MD5CryptoServiceProvider();
byte[] somme = check.ComputeHash(buffer);
string ret = “”;
foreach (byte a in somme)
{
if (a < 16)
ret += “0” + a.ToString(“X”);
else
ret += a.ToString(“X”);
}
return ret.ToLower();
}
catch
{
throw;
}
}
/// <summary>
/// base64编码
/// </summary>
/// <param name=”str”>内容</param>
/// <param name=”charset”>编码方式</param>
/// <returns></returns>
private string base64(String str, String charset)
{
return Convert.ToBase64String(System.Text.Encoding.GetEncoding(charset).GetBytes(str));
}
}
}
